The JWZ-EBM Full-Automatic Electric Blow Molding Machine is a cutting-edge solution designed to meet the highest industry standards. This professional-grade machine is ideal for producing a wide range of hollow blow-molded plastic products in various specifications.
With its fully automated production process, the machine guarantees superior precision and efficiency, enabling high output rates. It not only delivers exceptional results but also features low energy consumption, making it both an eco-friendly and cost-effective option.
Understanding that each customer has unique needs, our team is committed to providing a comprehensive package tailored to fulfill all your production requirements.
Fully Electric System: Achieves energy savings of 50%-60% compared to traditional hydraulic systems, promoting both energy efficiency and environmental sustainability.
Servo Motor Drive: Provides high movement accuracy, quick response times, and stable operation with smooth start/stop transitions.
Fieldbus Control: Integrates the entire system, enabling real-time monitoring of both the host and auxiliary machine, as well as efficient data collection and management.
Multi-Point Dynamic Wall Thickness Adjustment: Automatically adjusts data for smooth type embryo transitions, ensuring optimal performance.
Efficient Extruder: Features a high-efficiency screw for better output and reduced energy consumption.
Jwell Fifth-Generation U-Type Clamping Structure: Delivers uniform and stable clamping force, improving consistency.
Short Molding Cycle & High Cooling Efficiency: Maximizes productivity by reducing cycle times and improving cooling.
Automatic Production: Minimizes labor and management costs through fully automated operation.
Leakage-Free and Low Noise: Ideal for applications requiring high cleanliness standards, such as food, pharmaceuticals, and cosmetics.
Easy Maintenance: Simplifies maintenance of molds and carriage devices, offering low-cost, high-torque control.
Long opening stroke with precise linear movements
Available in single and double stations
Options for hydraulic, hybrid, or all-electric platforms
Enhanced clamping force with lower energy consumption
Trimming and leak testing performed online
Servo robot take-out system
Optional view stripes and co-extrusion features
AC inverter extruder drive controllers
Single and multi-parison die heads
Multi-layer, multi-cavity systems
Weighing feeding material system
Screen changer system
Online leak detection, visual inspection, packaging, and other automation solutions
| Name | Model | Unit | JWZ-EBM-420D JWZ-EBM-520D JWZ-EBM-650D JWZ-EBM-850D | ||||
| Main screw diameter | Main screw diameter | mm | 65 | 65 | 75 | 90 | |
| Screw L/D ratio | Screw L/D | / | 25:01:00 | 30:01:00 | 30:01:00 | 30:01:00 | |
| Screw speed | Screw rpm | r/min | 25-75 | 25-75 | 25-75 | 25-75 | |
| Extrusion volume | Max plasticizing capacity(PE) | kg/h | 65-75 | 100-105 | 110-130 | 180-200 | |
| Die Size | Platen size W*H | mm | 330X286 | 420X390 | 580X450 | 780*400 | |
| Mold thickness | Mould thickness | mm | 140 | 180 | 240 | 320 | |
| Clamping force | Clamping force | KN | 50 | 80 | 180 | 240 | |
| Empty cycle | Dry cycle | S | 2.9 | 3.2 | 4 | 4.8 | |
| Die shift stroke | Platen moving stroke | mm | 420 | 520 | 650 | 850 | |
| Note: lnformations listed above are for reference only, the production line can be designed by customer's requirements. | |||||||
