Jwell offers an extensive selection of polymer waterproof equipment, including:
Composite Polymer Waterproof Coiled Material Production Line: This line is designed for producing a variety of materials such as PVC, TPO, PE, and other waterproof coiled materials. It can accommodate different product structure forms.
Water Storage and Drainage Board Production Line: Traditional drainage methods use brick and stone tiles as the filter guide layer, with more pebbles or gravels serving as the filter layer to direct water to a specific location. Replacing the pebble filter layer with a water plate for drainage saves time, labor, energy, and investment, and also reduces the load on the building.
PE Waterproof Roll/Geomembrane Extrusion Line: This line is used for the roof waterproofing of industrial and civil buildings, including green roofs, flat roofs, sloping roofs, and underground waterproofing of structures such as reservoirs, dams, and pools. It is also used for waterproofing water tunnels, grain depots, civil defense projects, waste landfills, and artificial lakes. The PE Extra-width waterproof roll/geomembrane production line can achieve an ultra-wide width of 8.5m.
| Species | High Polymer Composite Waterproof Roll Extrusion Line | Water Drainage Sheet Extrusion Line | PE Extra-width Geomembrane/Waterproof Roll Extrusion Line |
| Model | JWS150—JWS120 | JWS-150 | JWS-150 |
| Material | PVC, TPO, PE | HDPE | PE |
| Production thickness(mm) | 1-2mm | 0.5-3.0 | 1-3MM |
| Products Width(mm) | 2000mm | 2000-5000mm | 1000-8500MM |
| Output (kg/h) | 1100 | 600 | 600 |
JWELL has extensive experience and a significant market share in the polymer waterproof coil production line industry. In China, the majority of leading waterproof coil manufacturers use JWELL's extrusion production lines.
JWELL is capable of producing CPE/EVA/ECB/PE waterproof coil production lines (used for CRCC certification by the Ministry of Railways), 8.5m extra-wide PE geomeme waterproof rolls, and compound five-roll polymer waterproof roll production lines. They also produce a variety of waterproof boards, geomemes, water storage, and drainage board production lines with different uses, widths, and outputs. JWELL has numerous successful cases, extensive experience, high output, competitive pricing, simple operation, and convenient maintenance.
The polymer waterproof roll material produced from the plate extrusion line has a wide range of applications and is used in large quantities. It is primarily categorized into the following types:
Plastic roll sheet (Model: H): This type does not have an inner reinforced material or outer coating.
Roll sheet with outer fiber (Model: L): This type is coated with fiber or non-woven fabric.
Inner reinforced roll sheet (Model: P): This type has an inner layer coated with polyester mesh.
Inner reinforced roll sheet (Model: G): This type has an inner layer coated with glass fiber.
These materials can be used in various sectors, including civil and industrial construction, rail transit, highway tunnels, artificial lakes, landfills, and more.
