Model | CJWS 75-52D |
Formulation | PE+ Mineral Powder+ Silane+Additive |
Capacity | ~500kg/h |
Customer | Russia |
Date | 2019 |
The equipment running stably and reliably, adopt high-speed rotating saw, Circular Saw blade cut the pipe. Suitable for extra thick large-diameter pipe; Cemented carbide cutting blades, high wear resistance and long service life; Powerful suction chips Dust removal used ionic wind, equipped with dust filters collection device.
In view of the large diameter PVC pipe is equipped with a dedicated chamfering cutter, tungsten carbide blade, sharp and durable; The internal structure of advanced design, make the PVC pipe cutter surface smooth and tidy, chamfer Angle and uniformity nice.
For small diameter PVC pipe, we had a special high-speed cutting machine dust-free. Ribbon cuttings avoid the pollution of dust on the work shop.
Model | GFQJ160 | GFQJ315 | GFQJ450 | GFQJ630 | GFQJ1200 | GFQJ1600 | GFQJ3000 |
Diameter(mm) | 20-160 | 50-315 | 110-450 | 200-630 | 400-1200 | 400-1600 | 1600-3000 |
Thickness(mm) | 20 | 35 | 50 | 70 | 155 | 155 | 155 |
Max Cutting frequency(1/min) | 4 | 3 | 2 | 2 | 0.5 | 0.5 | 0.2 |
Max Cutting Speed(m/min) | 20 | 8 | 3.5 | 1.5 | 0.8 | 0.8 | 0.1 |
Note | Dust-free cutting | Suitable for cutting PVC pipe, | Large diameter solid wall pipe sawing | ||||
Note: The specifications are subject to change without prior notice.
